Fluid

Air

Internal Pilot Operating Pressure Range

2 Position Single

0 . 15 ~ 0 . 7 MPa

2 Position Double

0 . 1 ~ 0 . 7 MPa

3 Position

0 . 2 ~ 0 . 7 MPa

Ambient and fluid Temperature

- 10 ~ 50 ℃ ( No freezing )

Max . operating frequency

2 Position Single , Double

10 Hz

5

5

5

3 Position

3 Hz

Manual override ( Manual operation )

Non – locking push type

Pilot exhaust method

Common exhaust type for main and pilot valve

Lubrication

Not required

Mounting orientation

Unrestricted
