Working medium

Air、Water、Oil、Gas

Operation

Pilot Operated

Acting Type

Normal Close

Office Size(mm)

17mm

22mm

30mm

50mm

CV value

4.8

12

20

48

Port Size

G3/8''

G1/2''

G3/4''

G1

G1 1/4''

G1 1/2''

G2''

Operation Fluid Viscosity

20CTS Below

Operating Pressure

0.1-1.5Mpa

Max. Pressure Resistance

2.25Mpa

Operating Temperature

-5~180℃

Voltage Range

±10%

Material of Body

Brass

Seal Material

PTEE
