Fluid

Air,Water,Oil (filterd through 40u filter element)

Acting

Direct acting

Internally piloted acting

Initial state

Normally closed type

Effective area(mm²)

2.5

2.5

13.0

13.0

25.0

25.0

CV Value

0.23

0.25

6.20

6.2

13

13

Port size

1/8''

1/4''

3/8''

1/2''

3/4''

1''

Viscosity limit

Under 20 CST

Pressure range

0~1.0MPa(0~145psi)

0.05~1.0MPa(7~145psi)

Proof pressure

1.5MPa(215psi)

Material body

Brass with zinc plated

Brass

Seal material

NBR

Activating time

0.05 sec and below
