2/2 Way Direct Acting Micro Brass Magentic Valve

2/2 Way Direct Acting Micro Brass Magentic Valve

2V025-08,Two-position two-way solenoid valve, normally closed solenoid valve, direct-acting solenoid valve, high temperature solenoid valve, steam solenoid valve, water and gas general solenoid valve, jery solenoid valve for medical machinery, cleaning equipment, food machinery, small household appliances, textile Machinery, pneumatic components, biopharmaceuticals, medical equipment, rubber and plastic machinery, clothing equipment, drying equipment, pharmaceuticals, HVAC, electroplating and coating machinery manufacturing and other industries. Suitable for automatic control of water, hot water, steam, gas.

Model

2V025-06

2V025-08

2V130-10

2V130-15

2V250-20

2V250-25




Working Medium

Air,water,Oil,Gas




motion pattern

direct drive type

Guide type



Type

Nomal close type



Aperture Of flow Rate

2.5

13

25



CV value

0.23

6.2

23



Joint pipe Bore

1/8"

1/4"

3/8"

1/2"

3/4"

1/2"



Operation Fluid Viscosity

20 CST(below)



Working-Preussure

Air,water,Oil:0~8

Air,water,Oil:0~7



Max.pressure Resistance

12

10.5



Operating Temperature Range

-10~80



Voltage Range

±10%



Protect class

IP65



power cosumption

AC:7VA/60HZ,9VA/50HZ,DC:6W
